Hands-free system for cellular phones

The hands-free system is a function that allows you to use your cellular phone without touching it.

This system supports Bluetooth® cellular phones. Bluetooth® is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.

Vehicles with a navigation system

Refer to the “Navigation System Owner’s Manual”.

Vehicles without a navigation system

 - Conditions under which the system will not operate

 - Conditions under which the system will not operate

• If using a cellular phone that does not support Bluetooth®

• If the cellular phone is switched off

• If you are outside service range

• If the cellular phone is not connected

• If the cellular phone’s battery is low

• If the cellular phone is behind the seat or in the glove box or console box

• If metal is covering or touching the phone

 - Signal status

This display may not correspond exactly with the cellular phone itself.

 - When using the hands-free system

• The audio system and voice guidance are muted when making a call.

• If both parties speak at the same time, it may be difficult to hear.

• If the incoming call volume is overly loud, an echo may be heard.

• Try to face toward the microphone as much as possible when speaking.

• In the following circumstances, it may be difficult to hear the other party:

• When driving on unpaved roads

• When driving at high speeds

• When a window is open

• When the air conditioning is blowing directly on the microphone

• When the air conditioning is set to high

 - When transferring ownership of the vehicle

Be sure to initialize the system to prevent personal data from being improperly accessed.

 - About Bluetooth®

Bluetooth is a registered trademark of Bluetooth SIG. Inc.

 - Compatible models

 - Compatible models

Compatible with HFP (Hands Free Profile) Ver. 1.5 and OPP (Object Push Profile) Ver. 1.1.

If your cellular phone does not support HFP, you cannot enter the Bluetooth® phone. If your cellular phone supports OPP alone, you cannot use the Bluetooth® phone.

 - Certification for the hands-free system

FCC ID: AJDK018

IC ID: 775E-K018

MADE IN JAPAN

This device complies with Part 15 of the FCC Rules and RSS-Gen of IC Rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

CAUTION

 - FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Radio Frequency Radiation Exposure. This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio fre- quency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and oper- ated with at least 7.9 in. (20 cm) and more between the radiator and person’s body (excluding extremities: hands, wrists, feet and legs).

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

 - Caution while driving

Do not use a cellular phone or connect the Bluetooth® phone.

NOTICE

 - To prevent damage to cellular phones

Do not leave cellular phones in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the phone.
