Emergency repairs
Lexus recommends having maintenance and repairs for your LX 570 performed by an authorized Lexus dealership.
To locate your nearest authorized Lexus dealership, log on to www.lexus.com or contact Lexus Customer Satisfaction at (800)255-3987.
Maintenance and repairs not performed by an authorized Lexus dealership should be performed by a qualified technician following procedures in Lexus service and repair publications.
If your vehicle is inoperable or unsafe to drive and there is no Lexus dealership reasonably available to make repairs, you may perform the repairs yourself or have them performed by another automotive service provider.
Lexus will reimburse you for any of the repairs that are covered by warranty.
To receive reimbursement, present to an authorized Lexus dealership your paid repair invoices and any parts that were removed from the vehicle. You will be reimbursed for warranted parts at the manufacturer’s suggested retail price and warranted labor at a geographically appropriate hourly rate multiplied by Lexus’ recommended time allowance for the repair.
If your vehicle requires emergency repair, Lexus assumes no liability for subsequent failures caused by improper repairs or the use of non- Genuine Lexus Parts unless you have the vehicle properly repaired in a timely manner. To ensure that warranty coverage remains intact, have your vehicle inspected by an authorized Lexus dealership as soon as possible after an emergency repair.
Regular maintenance is essential to obtaining the highest level of performance, safety and reliability from your Lexus. It can also enhance your vehicle’s resale value. This section of the Warranty and Services Guide is designed to help you make sure your vehicle receives proper and timely maintenance. It includes factory-recommended maintenance guidelines as well as logs in which to document your vehicle’s maintenance history.
In addition to scheduled maintenance, your Lexus requires ongoing general maintenance such as fluid checks and visual inspections. These procedures are listed on pages 42–43 of this booklet and described in detail in the “Maintenance” section of the Owner’s Manual.
It is especially important to check your vehicle’s engine oil once a month and to regularly replace the engine oil and oil filter. Failure to do so can cause oil starvation and/or oil gelling, which can result in severe damage to your vehicle and require costly repairs that are not covered by the New Vehicle Limited Warranty. With proper maintenance and care, your vehicle will last longer and deliver more dependable, economical performance. Follow this booklet’s recommendations and you’ll enjoy maximum reliability and peace of mind from your Lexus for many years to come.
Maintaining your vehicle according to the recommendations in this booklet is required to ensure that your warranty coverage remains intact. You should keep detailed records of vehicle maintenance, including date of service, mileage at time of service and a description of service and/or parts installation performed. The maintenance logs in this booklet are a good place to record this information.
If you sell your vehicle, be sure to give your maintenance records to the new owner.
Lexus will not deny a warranty claim solely because you do not have records to show that you maintained your vehicle. However, damage or failures caused by lack of proper maintenance are not covered under warranty.
Maintenance and repair services may be performed by you or by any automotive service provider you choose.
Lexus will not deny a warranty claim solely because you used a service provider other than a Lexus dealership for maintenance and repairs.
However, damage or failures caused by improper maintenance or repairs are not covered under warranty.
Your dealer may recommend more frequent maintenance intervals or more maintenance services than those listed in the scheduled maintenance log. These additional services are not required to maintain your warranty coverage. Ask your dealer for an explanation of any recommended maintenance not included in the scheduled maintenance log.
To ensure that your vehicle receives first-quality service and factoryauthorized parts, Lexus recommends having maintenance performed by an authorized Lexus dealership. To locate your nearest authorized Lexus dealership, log on to www.lexus.com or contact Lexus Customer Satisfaction at (800)255-3987.
Lexus dealership technicians are experts in the maintenance and repair of Lexus vehicles. They stay current on the latest service information through Lexus technical bulletins, service publications and training courses. Many are also certified through the Lexus Commitment to Perfection Certification Program, which requires specialized, state-ofthe- art training as well as rigorous exams through both Lexus and the National Institute for Automotive Service Excellence.
Additionally, when you have your vehicle serviced at a Lexus dealership, your service information is recorded in the Lexus National Service History database. This is the first database of its kind in the automotive industry. It can be accessed by any Lexus dealership in the U.S. — a great convenience if you relocate or need to have your vehicle serviced while traveling.
You can be confident you’re getting the best possible service for your vehicle when you take it to a Lexus dealership. Don’t trust your investment to anything less than a team of Lexus specialists.
Maintenance and repairs not performed by an authorized Lexus dealership should be performed by a qualified technician following procedures in Lexus service and repair publications.
In addition to scheduled maintenance, your Lexus requires ongoing general maintenance such as fluid checks and visual inspections. The recommended guidelines for inspections are listed below. Please refer to the “Maintenance” section of the Owner’s Manual for a detailed description of inspection procedures.
Every 30 Days
• Check engine oil level using
the dipstick
• Visually check engine coolant
level on the see-through
reservoir
• Visually check brake fluid level
on the see-through reservoir
• Check level of power steering
fluid
• Visually check condition of
battery
• Check level of windshield
washer fluid
• Check installation of driver’s
floor mat
• Check tire pressure
• Check tires for damage
and wear
After a Car Wash
• Check installation of driver’s
floor mat
After Off-Road Driving
Whenever you drive off-road through
deep sand, mud or water, perform
these inspections daily:
• Check axle shaft boots
• Check ball joints and dust covers
• Check brake lines and hoses
• Check brake pads/rotors and
parking brake linings/drums
• Check differential oil
• Check engine air filter
• Check nuts and bolts on chassis
• Check steering linkage and
boots
• Check transfer case oil
• Check transmission fluid
When Cleaning the Interior
• Remove dirt and dust with a
vacuum cleaner. Wipe dirty surfaces
with a soft cloth dampened
with warm water.
• When cleaning leather interior,
remove dirt and dust with a
vacuum cleaner. Using a sponge,
apply a small amount of neutral
wool detergent mixed in water,
rubbing in a circular motion.
Wipe off any excess detergent
and let leather dry in an open-air
location.
• When cleaning carpet, remove
dirt and dust with a vacuum
cleaner. Apply a foaming-type
carpet cleaner with a sponge or
brush, allowing cleaner to work
for a few minutes to loosen dirt.
Continue by rubbing carpet in a circular motion. Wipe off any excess cleaner with a clean cloth.
If any dirt remains, repeat process.
Best results are obtained by keeping the carpet as dry as possible.
When Cleaning the Exterior
• Working from top to bottom,
apply lots of low-pressure water
to the body, wheel wells and
underside of vehicle to remove
dirt and dust. Wash the vehicle
body using a soft sponge or
cotton cloth with mild car-wash
soap. Rinse off with water.
• If water does not bead on a clean
vehicle surface, apply car wax
using a soft cotton cloth when
the body of the vehicle is cool.
When Cleaning the Wheels
• Wait for hot wheels to cool
before getting wheels wet.
• Using a soft sponge or cotton
cloth, apply same mild car-wash
soap as used for the vehicle
body. Quickly rinse off with
water. Using a soft cotton cloth,
apply same car wax as used for
the vehicle body.
Determining Your
Maintenance Interval:
Months vs. Mileage
Lexus recommends obtaining scheduled
maintenance for your vehicle
every six months or 5,000 miles,
whichever occurs first.
For example:
• If at six months you have driven
less than 5,000 miles, you
should obtain maintenance at six
months; don’t wait until 5,000
miles.
• If you drive 5,000 miles in less
than six months, you should
obtain maintenance at 5,000
miles; don’t wait until six months.
Be sure to keep an eye on your mileage so that you obtain maintenance when recommended. If you are a low-mileage driver, mark your calendar to remind yourself to obtain maintenance every six months.
Special Operating Conditions
In addition to standard maintenance
items, vehicles that are driven under
special operating conditions require
further maintenance service. These
special operating conditions, which
put added demands on a vehicle,
include:
• Driving on dirt roads or on dusty
roads
• Repeated trips of less than five
miles in temperatures below
32° F or 0° C
• Extensive idling and/or lowspeed
driving for long distances,
such as police, taxi or door-todoor
delivery use
If you drive primarily under any of the conditions noted, you should replace the engine oil and oil filter every six months or 5,000 miles. Some of these special operating conditions require other maintenance items; these items are indicated in each maintenance chart.
If you drive only occasionally under any of the special operating conditions noted, it is not necessary to change the oil every six months or 5,000 miles or to perform the additional services listed in the charts. This added maintenance is required only if you drive primarily under any of the special operating conditions.
Complimentary First
Scheduled Maintenance
Service: Six Months or
5,000 Miles
Lexus provides your first scheduled
maintenance service at no charge.
The service is performed at six
months or 5,000 miles, whichever
occurs first. To obtain this service,
contact your Lexus dealership. Your
complimentary service will include
these items:
• Inspect and adjust all fluid levels
• Program Lexus Personalized
Settings, if requested
• Reset maintenance reminder
light
• Rotate tires
• Visually inspect brake pads,
calipers and rotors
• Check installation of driver’s
floor mat
• Road-test vehicle
What are Lexus Personalized
Settings?
Your vehicle includes a variety of
electronic features that can be programmed
to your preferences. For
example, doors can be programmed
to remain locked when you shift into
“Park.” (For more information, see the
“Customizable Features” section of
the Specifications chapter in your
Owner’s Manual.) Programming of
these features is performed once at
no charge, provided you obtain the
service at the six-month/5,000-mile
scheduled maintenance service.
Programming of some Lexus Personalized Settings requires special equipment and may be performed only by an authorized Lexus dealership.
Complimentary Second
Scheduled Maintenance
Service: 12 Months or
10,000 Miles
Lexus also provides your second
scheduled maintenance service at no
charge. The service is performed at
12 months or 10,000 miles, whichever
occurs first. To obtain this service,
contact your Lexus dealership. Your
complimentary service will include
these items:
• Replace engine oil with 0W-20
oil; replace oil filter
• Reset maintenance reminder
light
• Rotate tires
• Visually inspect brake pads,
calipers and rotors
• Check installation of driver’s
floor mat
• Road-test vehicle
If you do the majority of your driving under certain special operating conditions, additional items are included in this service. See the “12 Months or 10,000 Miles” chart on page 48.
